Type
|
Type |
Digital, single-lens reflex, AF/AE camera with built-in flash |
Recording media |
SD/SDHC*/SDXC* memory cards
* UHS-I cards supported |
Image sensor size |
Approx. 22.3 x 14.9 mm |
Compatible lenses |
Canon EF lenses (including EF-S lenses)
* Excluding EF-M lenses
(35mm-equivalent angle of view is that of a lens with approx. 1.6x the focal length indicated.) |
Lens mount |
Canon EF mount |
Image Sensor
|
Type |
CMOS sensor (Compatible with Dual Pixel CMOS AF) |
Effective pixels |
Approx. 24.1 megapixels
* Rounded to the nearest 100,000. |
Aspect ratio |
3:2 |
Dust deletion |
Auto, Dust Delete Data appending |
Recording System
|
Recording format |
Design rule for Camera File System (DCF) 2.0 |
Image type |
JPEG, RAW (14-bit Canon original), C-RAW (Canon original), RAW +JPEG Large simultaneous recording possible |
Pixels recorded |
L (Large) : 24.0 megapixels (6000 x 4000)
M (Medium) : Approx. 10.6 megapixels (3984 x 2656)
S1 (Small 1) : Approx. 5.9 megapixels (2976 x 1984)
S2 (Small 2) : Approx. 3.8 megapixels (2400 x 1600)
RAW/C-RAW : 24.0 megapixels (6000 x 4000) |
Aspect ratio |
3:2, 4:3, 16:9, 1:1 |
Folder Creation/selection |
Possible |
File numbering |
Continuous, Auto reset, Manual reset |
Image Processing During Shooting
|
Picture Style |
Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined 1 – 3 |
White balance |
Auto (Ambience priority), Auto (White priority), Preset (Daylight, Shade, Cloudy, Tungsten light, White fluorescent light, Flash), Custom
White balance correction, and White balance bracketing provided
* Flash color temperature information transmission possible |
Noise reduction |
Applicable to long exposures and high ISO speed shots |
Automatic image brightness correction |
Auto Lighting Optimizer provided |
Highlight tone priority |
Provided |
Lens aberration correction |
Digital Lens Optimizer, Peripheral illumination correction, Distortion correction, Chromatic aberration correction, Diffraction correction |
Viewfinder
|
Type |
Eye-level pentamirror |
Field of view coverage |
Vertical/Horizontal approx. 95%
(with Eye point approx. 19 mm) |
Magnification |
Approx. 0.87x (–1 m-1 with 50mm lens at infinity) |
Eyepoint |
Approx. 19 mm (from eyepiece lens center at –1 m-1) |
Dioptric adjustment range |
Approx. –3.0 – +1.0 m-1 (dpt) |
Focusing screen |
Fixed, Precision Matte |
Mirror |
Quick-return type |
Depth-of-field preview |
Available (with customized DISP button setting) |
Autofocus (for viewfinder shooting)
|
Type |
TTL secondary image-registration, phase-difference detection with the dedicated AF sensor |
AF points |
9-point AF (Center point: cross-type, vertical line sensitive when supporting f/2.8) |
Focusing brightness range |
EV –0.5 – 18 (with the center AF point supporting f/2.8, One-Shot AF, at room temperature, ISO 100) |
Focus operation |
One-Shot AF, AI Servo AF, AI Focus AF, Manual focusing (MF) |
AF-assist beam |
Built-in flash: Intermittent firing
External Speedlite: Infrared firing, Intermittent firing |
Exposure Control
|
Metering mode |
63-zone TTL open-aperture metering
・Evaluative metering (linked to all AF points)
・Partial metering (approx. 9.0% of viewfinder at center)
・Spot metering (approx. 4.0% of viewfinder at center)
・Center-weighted average metering |
Metering brightness range |
EV 1 – 20 (at room temperature, ISO 100) |
Shooting mode |
Basic Zone modes:
Scene Intelligent Auto, Special scene modes (Portrait, Smooth skin, Group Photo, Landscape, Sports, Kids,Close-up, Food, Candlelight, Night Portrait, Handheld Night Scene, HDR Backlight Control), Creative filters (Grainy B/W, Soft focus, Fish-eye effect, Water painting effect, Toy camera effect, Miniature effect, HDR art standard, HDR art vivid, HDR art bold, HDR art embossed)
Creative Zone modes:
Program AE, Shutter-priority AE, Aperture-priority AE, Manual exposure |
ISO speed
(Recommended exposure index) |
Basic Zone modes: ISO speed set automatically
Creative Zone modes: ISO Auto, ISO 100 – 25600 set manually (whole-stop increments), and ISO expansion to H (equivalent to ISO 51200) provided |
Exposure compensation |
Manual : ±5* stops in 1/3- or 1/2-stop increments
* ±3 stops with [Shooting screen: Guided] set
AEB: ±2 stops in 1/3- or 1/2-stop increments (can be combined with manual exposure compensation) |
AE lock |
Auto: Applied in One-Shot AF with evaluative metering when focus is achieved
Manual : With AE lock button |
Shutter
|
Type |
Electronically-controlled, focal-plane shutter |
Shutter speed |
Basic Zone modes: 1/4000 – 1 sec.
Creative Zone modes: 1/4000 – 30 sec., bulb |
Drive System
|
Drive mode |
Single shooting, Continuous shooting, Silent single shooting, Silent continuous shooting
Self-timer: 10 sec / remote control*, 2 sec, Continuous
* When Wireless Remote Control BR-E1 (sold separately) is used. |
Continuous shooting speed |
Max. approx. 5.0 shots/sec.
Silent continuous shooting: Max. approx. 2.5 shots/sec. |
Max. burst |
JPEG Large/Fine: Full
RAW: Approx. 10 shots
C-RAW: Approx. 37 shots
RAW+JPEG Large/Fine: Approx. 9 shots
C-RAW+JPEG Large/Fine: Approx. 17 shots
* The number of possible shots and standard maximum burst apply to a UHS-I compliant 32 GB card based on Canon testing standards.
* Maximum burst varys depending on shooting conditions (including aspect ratio, subject, memory card brand, ISO speed, Picture Style, and Custom Function).
* ”Full” indicates that shooting is possible until the card becomes full. |
Flash
|
Built-in flash |
Retractable flash
Guide No.: Approx. 9.8/32.1 (ISO 100, in meters/feet)
Flash coverage: Approx. 18mm lens angle of view
Recharge time: Approx. 3 sec. |
External Speedlite |
Compatible with EL/EX-series Speedlites |
Flash metering |
E-TTL II autoflash |
Flash exposure compensation |
Built-in flash: ±2 stops in 1/3- or 1/2-stop increments
External Speedlite: ±3 stops in 1/3- or 1/2-stop increments |
FE lock |
Provided |
PC terminal |
Not provided |
Flash control |
Built-in flash function settings, external Speedlite function settings, external Speedlite Custom Function settings |
Live View Shooting
|
Focus method |
Dual Pixel CMOS AF system |
AF method |
Face+Tracking, Zone AF, 1-point AF, Spot AF
Manual focus (approx. 5x / 10x magnification available for focus check) |
AF operation |
One-Shot AF, Servo AF |
Focusing brightness range |
EV –4 – 18 (with the center AF point, at room temperature, f/1.2, ISO 100, One-Shot AF) |
Metering mode |
Real-time metering using the image sensor
384-zone (24×16) metering
Still photo shooting:
・Evaluative metering (linked to all AF points)
・Partial metering (approx. 5.5% of screen, at center)
・Spot metering (approx. 3.7% of screen, at center)
・Center-weighted average metering |
Metering brightness range |
EV –2 – 20 (at room temperature, ISO 100) |
Exposure compensation |
±3 stops in 1/3-stop or 1/2-stop increments |
Creative filters |
Provided |
Touch Shutter |
Provided |
Grid display |
Three types |
